Notes:
Material:
Housing: High Temperature Thermoplastic
Terminal: Copper Alloy, 50u" Ni Under Plated Over All
1u" Au Plated On Contact Area And Solder Area
Shell: Stainless Steel, 50u" Ni Under Plated Over All
Technical Speciality:
Rated Voltage: 30V AC Max
Current Rating: 0.5A Max
Insulation Resistance: 1000MΩ Min
Contact Reistance: 100mΩ Max
Withstanding Voltage: 500V AC For 1 Minutes
Operating Temperature: -20°C ~ +85°C Humidity 80% R.H Max |
